Advanced Electrical Designing Module


Software with a unique approach to the sizing of Cables, Conduit and Trunking

Based in Microsoft Excel, our Advanced Electrical Designing software will help you to select the correct cable for the job.
Click button below to watch our video demo:


Software includes:

• Cable Sizing Calculators

XLPE SWA  Cables
Click to view screenshot below

• 6942XLH - 2 core XLPE Armoured Cable (90°C)

• 6943XLF - 3 core XLPE Armoured Cable (90°C)

• 6944XLF - 4 core XLPE Armoured Cable (90°C)

Single Core Cables
Click to view screenshot below

• 6491X - 2 X PVC Single Core Cables (70°C)

• 6491B - 2 X LSF Single Core Cables (90°C)

• 6491X - 3/4 X PVC Single Core Cables (70°C)

• 6491B - 3/4 X LSF Single Core Cables (90°C)

Twin and Earth Cables
Click to view screenshot below

• 6242YH - PVC Insulated and Sheathed flat cables (70°C) - Installation Methods 101# 102# & 103#

• 6242BH - LSF Insulated and Sheathed flat cables (90°C) - Installation Methods 101# 102# & 103#

• Conduit Sizing Calculator  View screenshot

• Trunking Sizing   View screenshot

• Load Diversity Calculator   View screenshot

• Electrical Drawing Tool   View screenshot

• Plus other useful features

Software Demo
